Gravely Pro-Turn 660 EFI Zero-Turn Mower

Gravely Pro-Turn 660 EFI Zero-Turn Mower

Handling more work in less time, the Pro-Turn 660 EFI unit cuts faster and more efficiently. Its Operator Pod System is unlike any other and was designed to keep you mowing comfortably. It separates the operator from the bouncing and jostling the mower encounters, even on the roughest of terrains. You’ll feel as light as air, while still being in ultimate control.

This unit’s X-Factor 3 Deck has been completely redesigned for better grass dispersion. Its new look is constructed from high-quality 7-gauge steel to deliver years of solid performance. It features large diameter tires for a smoother ride and more traction in a range of conditions. The Pro-Turn 660 EFI is the best choice for any commercial job that requires a sturdy unit.

Specifications

Warranty Information

Domestic Warranty 5 Year / 1500 Hour Domestic Warranty
Commercial Warranty 5 Year / 1500 Hour Commercial Warranty

Dimension Specs

Dry Weight 726.2 kg
Height 1816 mm with ROPS Up, 1214 mm with ROPS Down
Width 1600 mm with chute up
Overall Length 2108 mm

Zero Turn Mower Specs

Ground Speed – Forward 24.1 km/h
Ground Speed – Reverse 9.6 km/h
Brakes Hand Park Brake
Seat High back bolstered with suspension POD system
Construction Frame 1″ x 3″ STEEL Tubular frame welded
ROPS Foldable ROPS Standard
Controls Hand-operated choke, throttle, ignition switch, electric mower clutch, hand park brakes
Cup Holder Yes
Deck System Fabricated X-Factor 3
Deck Lift Foot operated
Deck Construction Fabricated 7 Gauge with ¼” spindle reinforcement
Blade Tip Speed 18,000 FPM
Spindles Forged Aluminium with sealed ball bearings
Drive System Parker HTG 16cc Dual Hydrostatic Transmission
Discharge Chute High density, rubberised
Steering Twin-lever steering provides independent control of each drive wheel. Speed, forward, reverse, and turns are all controlled with hand-operated controls

Engine and Fuel Specs

Engine Kawasaki FX1000V EFI
Type Air cooled, 90-degree V-twin, normally aspirated petrol engine
Engine (cc) 999 cc
Horsepower 38.5 hp
Cooling Air cooled flywheel fan
Fuel Unleaded fuel – maximum of 10% ethanol in fuel (see engine manufacturers specifications)
Fuel Filter Replaceable, automotive-type
Oil Filter Spin-on engine oil filter / Total oil capacity 1.9 litres with filter
Air Filter Multi-Stage remote canister heavy duty air filter system
Fuel Capacity 47.9 L
Governor Mechanical

Safety Features

Safety Features Operator presence system connected to clutch, seat, and park brakes

Mowing Deck Specs

Kit – Mulch Available Optional Accessory

Hydrostatic Drive System Specs

Hydrostatic Drive System Dual hydrostatic
Drive Cooling Transmission mounted fans
Transmission Parker HTG Transmission

Cutting Dimensions

Cutting Widths 60″ (1524 mm) side discharge
Cutting Height(s) 19 Cutting positions / 25 mm – 140 mm
